| Cooling Capacity, kW |
5.00 |
| Heating Capacity, kW |
5.50 |
| Power Supply |
~220-240V/50Hz/1 Ph |
| Power Consumption, kW |
1.55/1.60 |
| Seasonal Energy Efficiency Ratio SEER (cooling) |
6.10 (A++) |
| Seasonal Coefficient of Performance SCOP (heating) |
4.00 (A+) |
| Air Flow Rate, m³/h |
850 |
| Refrigerant |
R32 |
| Refrigerant Quantity, Kg |
1.00 |
| Weight (Indoor Unit / Outdoor Unit), Kg |
26/39 |
| Cooling Operation Outdoor Temperature Range, ºC |
-20 / +48 |
| Heating Operation Outdoor Temperature Range, ºC |
-20 / +24 |
| Indoor Unit Dimensions, mm |
870X235X665 |
| Outdoor Unit Dimensions, mm |
887x396x302 |
| Liquid Pipe Diameter (mm) |
6.38/1/4″ |
| Gas Pipe Diameter (mm) |
12.70/1/2″ |
| Maximum Refrigerant Line Length, m |
35 |
| Maximum Refrigerant Line Height, m |
20 |
| Communication Cable, mm |
2 x 0.75 |
| Power Supply Cable, mm |
3 x 1.5 |
| Maximum Line Length Without Refrigerant Supply, m |
5 |
| Additional Refrigerant Supply, g/m |
16 |
