Supreme Continental CH-S24FTXAL

SKU: CH-S24FTXAL (E) Categories: Seria SUPREME CONTINENTAL, Split systems, Residential

The Supreme Continental series air conditioners combine the modern design of the Supreme indoor unit with the power of the Arctic series. These units are designed to perform under a wide range of temperature settings, offering cooling and heating capabilities suitable for temperate climates. They have a sleek, modern look and seamlessly fit into any decor.
Technical Specifications

Become a Partner

Color

Clear

Product Description

Technical Parameters Cooper & Hunter CH-S24FTXAL-GD/SC/BL/WP/FB:

Cooling capacity, kW	7.00 (2.00-8.32)
Heating capacity, kW	7.20 (2.00-9.20)
Energy consumption, kW	Cooling: 2.00 (0.40-3.70) / Heating: 1.85 (0.45-3.80)
Noise level	32/35/38/42/44/47/49 dB
Seasonal Energy Efficiency Ratio (SEER) Cooling	7.0 (A++)
Seasonal Coefficient of Performance (SCOP) Heating	5.2 (A+++)
Air flow, m³/h	750/850/900/950/1000/1100/1250
Outdoor unit dimensions, mm	965x700x396
Indoor unit dimensions, mm	1101x327x249
Refrigerant	R32
Operating temperature range cooling, ºC	-15/+43
Operating temperature range heating, ºC	-25/+24
Maximum refrigerant line length, m	25
Maximum refrigerant line height, m	10
Gas pipe diameter, mm	15.88/5/8″
Liquid pipe diameter, mm	6,38/1/4″
