Technical Parameters Cooper&Hunter CH-IF100RK:
| Cooling Capacity, kW | 10.00 |
| Heating Capacity, kW | 12.00 |
| Power Supply | ~380-415V/50Hz/3 Ph |
| Power Consumption, kW | 3.30/3.50 |
| Seasonal Energy Efficiency Ratio SEER (Cooling) | 6.10 (A++) |
| Seasonal Coefficient of Performance SCOP (Heating) | 4.00 (A+) |
| Air Flow Rate, m³/h | 1600 |
| Refrigerant | R32 |
| Refrigerant Quantity, Kg | 2.50 |
| Weight (Indoor / Outdoor Unit) | 32/89 |
| Operating Temperature Range (Cooling), ºC | -20/+48 |
| Operating Temperature Range (Heating), ºC | -20/+24 |
| Indoor Unit Size, mm | 1200x265x665 |
| Outdoor Unit Size, mm | 940x820x530 |
| Liquid Pipe Diameter, mm | 9.53/3/8″ |
| Gas Pipe Diameter, mm | 15.88/5/8″ |
| Maximum Refrigerant Line Length, m | 65 |
| Maximum Refrigerant Line Height, m | 30 |
| Communication Cable, mm | 2 x 0.75 |
| Power Supply Cable, mm | 5 x1.5 |
| Maximum Line Length Without Refrigerant Supply, m | 5 |
| Additional Refrigerant Charge, g/m | 40 |
